SANWA · Digital Multimeters

PC7000

Dual-display True RMS multimeter with optional PC Link.

  • True RMS
  • CAT III 600 V
  • PC Link

The SANWA PC7000 is a digital multimeter for users measuring voltage, current, resistance, capacitance, temperature and frequency. It combines True RMS AC measurement with a VFD low-pass filter and PC Link through the optional KB-USB7. Bhumika quotes this model as SANWA’s authorized Canadian distributor.

View quote basket

SANWA PC7000 digital multimeter
Manufacturer image — prototype placeholder.

Features

  • Dual display with 41-segment bar graph
  • True RMS AC voltage measurement
  • VFD low-pass filter
  • Capture/peak hold at 0.8 ms
  • MAX/MIN/AVG
  • PC Link via optional KB-USB7
  • 4–20 mA% function

Specifications

Measurement
DC voltage500 mV – 1000 V; ±(0.03%+2); resolution 0.01 mV
AC voltage (True RMS)500 mV – 1000 V; ±(0.5%+40)
DC / AC current500 µA – 10 A; ±(0.1%+20) DC / ±(0.6%+40) AC
Resistance500 Ω – 50 MΩ; ±(0.2%+6)
Conductance99.99 nS
Capacitance50 nF – 25 mF
Temperature−50 to 1000 °C; K-type
Frequency10 Hz–200 kHz
Duty cycle0.1–99.99%
dBm−29.83 to +54.25 dBm
Display & Functions
Display50,000 count (500,000 for DC voltage); dual display; 41-segment bar graph
FunctionsVFD low-pass filter; capture/peak hold 0.8 ms; MAX/MIN/AVG; 4–20 mA%
InterfacePC Link via optional KB-USB7
Safety
RatingIEC 61010 CAT III 600 V / CAT II 1000 V
Power & Physical
Power9 V ×1; approx. 100 h
Dimensions184 × 86 × 52 mm
MassApprox. 430 g including holster

Optional accessories

  • KB-USB7
